Pyramid CO2 Portable Fire Extinguisher

The Pyramid CO2 (carbon dioxide) portable fire extinguisher is a hand-operated unit ideal for electrical fires and sensitive equipment where a clean, residue-free extinguishing agent is required. Manufactured by Albtran Fire Fighting Systems under the Pyramid brand, it is built and tested to Egyptian Standard Specifications ES 735/2015 and ES 6115/2007.

Key Features

Seamless, one-piece factory-manufactured steel cylinder
Brass valve, nickel-chrome plated, fitted with a pressure check valve
Manual compressor valve with circular ring activation
High-pressure discharge hose with nozzle at the end for directed discharge
Body electrostatically coated with red polyester after surface treatment for corrosion resistance
Fitted with a suitable base to protect the cylinder from rust
Permanent, non-removable data plate with manufacturer details and operating instructions

Technical Specifications

Capacity	3 KG	6 KG	10 KG	12 KG	20 kg
Working Pressure	150 bar
Test Pressure	250 bar
Burst Pressure	≥400 bar
Operating Temperature	-20°C to +70°C
Extinguishing Agent	CO2

Certifications & Compliance

Egyptian Standard Specification ES 735/2015 (2–3–6 KG)
Egyptian Standard Specification ES 6115/2007 (10–20 KG)
ISO 9001:2015 Quality Management System
ISO 14001:2015 Environmental Management System
ISO 45001:2018 Occupational Health & Safety Management System

Warranty: 2 years from date of purchase against manufacturing defects.
