GST DI-9102E Intelligent Photoelectric Smoke Detector
GST DI-9102E Intelligent Photoelectric Smoke Detector
The DI-9102E Intelligent Photoelectric Smoke Detector is an addressable fire detection device that builds a fire alarm system together with a fire alarm panel and other alarm devices. Using light-scattering technology, the detector is suitable for hotels, restaurants, office buildings, schools, banks, warehouses, libraries, computer rooms, switch rooms, and more.
Features & Benefits
- Electrically addressed, can be modified by programmer
- Strong environmental adaptability due to drift compensation
- Self-diagnostic, reed switch test
- Dirty chamber checking
- Fire LED allows 360° viewing
- Possible to switch off polling LED
- Remote indicator output
- Removable innovative sensing chamber, easy for maintenance
- 2 levels sensitivities programmable (Level 1 certified)
- LPCB approved at EN 54-7
Technical Specification
| Operating Voltage | Loop 24V (16V ~ 28V) |
| Standby Current | ≤0.8mA |
| Alarm Current | ≤1.8mA (without remote indicator) / ≤3.8mA (with remote indicator) |
| Indicator | Red. Flashes in polling, and illuminates in alarm |
| Programming Method | Electronically programming |
| Code Range | 1 ~ 242 |
| Sensitivity Level | 2 |
| Wiring | Non-polarized 2-core for loop; polarized 2-core for remote indicator |
| Environment Temperature | -10°C ~ 50°C |
| Relative Humidity | ≤95%, non-condensing |
| Material of Enclosure | ABS |
| Ingress Protection Rating | IP2X |
| Dimensions | Diameter: 100mm, Height: 54.5mm (with base) |
| Mounting Hole Distance | 45mm ~ 75mm |
| Weight | About 110g |
Certificates & Compliance
- Standards: EN54-7
- Certifications: LPCB
Compatible Products
- GST100 Intelligent Fire Alarm Control Panel
- GST200-2 Intelligent Fire Alarm Control Panel
- GST200N Intelligent Fire Alarm Control Panel
- GST-IFP8 Intelligent Fire Alarm Control Panel
Accessories & Tools
- DB-01 — Standard Base (Product No. 30205764)
- DC-9504E — Base Mount Isolator (Product No. 10105103)
- C-9314P — Remote Indicator (Product No. 10102339)
- P-9910B — Handheld Programmer (Product No. 10104894)
Part No.: DI-9102E · Product No.: 10106287
