GST DI-9103E Intelligent Rate of Rise and Fixed Temperature Heat Detector
GST DI-9103E Intelligent Rate of Rise and Fixed Temperature Heat Detector
The DI-9103E Intelligent Rate of Rise and Fixed Temperature Heat Detector is an addressable fire alarm device that works with GST intelligent fire alarm control panels to build a complete fire detection system. The detector indicates fire alarm status via its LED indicator and transmits the signal directly to the Fire Alarm Control Panel (FACP).
Features & Benefits
- Electrically addressed, can be modified by programmer
- Self-diagnostic
- Reed switch test
- Fire LED allows 360° viewing
- Possible to switch off pulling LED
- Remote indicator output
- 3 classes programmable (A1R, A2S, BS)
- LPCB approved at EN54-5
Technical Specification
| Operating Voltage | Loop 24V (16V ~ 28V) |
| Standby Current | ≤0.6mA |
| Alarm Current | ≤1.5mA (without remote indicator) / ≤3.5mA (with remote indicator) |
| Indicator | Red. Flashes in polling, illuminates in alarm |
| Programming Method | Electronically programming |
| Code Range | 1 ~ 242 |
| Classes and Setup | 3 classes (A1R, A2S, BS) |
| Wiring | Non-polarized 2-core for loop; polarized 2-core for remote indicator |
| Ambient Temperature | Class A1: -10°C~+50°C / Class A2: -10°C~+50°C / Class B: -10°C~+65°C |
| Typical Fixed Temperature | Class A1: 58°C / Class A2: 62°C / Class B: 77°C |
| Relative Humidity | ≤95%, non-condensing |
| Material of Enclosure | ABS |
| Ingress Protection Rating | IP2X |
| Dimensions | Diameter: 100mm, Height: 53.3mm (with base) |
| Mounting Hole Distance | 45mm ~ 75mm |
| Weight | About 110g |
Certificates & Compliance
- Standards: EN54-5
- Certifications: LPCB
Compatible Products
- GST100 Intelligent Fire Alarm Control Panel
- GST200-2 Intelligent Fire Alarm Control Panel
- GST200N Intelligent Fire Alarm Control Panel
- GST-IFP8 Intelligent Fire Alarm Control Panel
Accessories & Tools
- DB-01 — Standard Base (Product No. 30205764)
- DC-9504E — Base Mount Isolator (Product No. 10105103)
- C-9314P — Remote Indicator (Product No. 10102339)
- P-9910B — Handheld Programmer (Product No. 10104894)
Part No.: DI-9103E · Product No.: 10106289
