Conv. Fire Alarm Control Panel 16 Zone-GST116A
GST116A Conventional Fire Alarm Control Panel
The GST116A Conventional Fire Alarm Control Panel is designed in compliance with EN 54-2 1997 + A1: 2006 and EN 54-4 1997+A1: 2002+A2:2006 standards. It's compatible with GST conventional detectors, manual call points, and sounders. The panel is easy to install and operate — control functions are enabled by a key switch, and programming functions are enabled by a key switch and an internal switch.
Features & Benefits
- 16 zones. Each zone can have a maximum of 32 conventional detectors; the total number of detectors and call points in a zone shall not exceed 32
- Each zone can be programmed to work as fire alarm (default) or supervisory alarm mode
- Each zone includes 2 indicators — a bi-color (red/green) indicator for fire/supervisory condition, and an amber fault/disable/test indicator
- 1× Alarm output, settable as 24V or N/O, N/C
- 3× sounder outputs — output 1 can be set as 24V or N/O, N/C; outputs 2 and 3 work as 24V only
- 1× Disable/supervisory relay output (N/O, COM, N/C)
- 1× Fault output (N/O, COM, N/C)
- 1× Auxiliary power output: 450mA in standby, up to 1000mA in alarm mode
- Reports short circuit and open circuit of detection zones, sounder outputs, and alarm output
- Designed with standby batteries and space provision for two sealed lead-acid batteries
- Easy operation to enable/disable zones, sounder outputs, and alarm output
- Alarm Test function selectable with or without sounder notification
- Output programmable for interlink between zones and sounder outputs, alert or evacuate tone, with or without delay
- Different Silence/Reset/Test modes selectable to meet local requirements
- Remote controls available for silence, evacuate, and reset
- Three access levels settable via key control
- Reserved repeater panel interface for fire alarm indication of multiple zones
Technical Specification
| Primary Supply | 220/230VAC +10%/-15%, 50/60Hz |
| Standby Power | 7AH/24VDC |
| Maximum Internal Resistance of Batteries | 1Ω |
| Zone Quantity | 16 |
| Device Capacity | 32 detectors per zone |
| End of Line for Zone | AEOL (active end of line) or EOLR (0.5Watt/4.7kΩ) |
| End of Line for Others | EOLR (0.5Watt/4.7kΩ) — sounder output, alarm output |
| Protection | IP30 |
| Standard | EN54-2 1997 + A1: 2006, EN 54-4 1997+A1: 2002+A2:2006 |
| Approval | LPCB |
| Operating Environment | 0°C ~ +40°C, ≤95% non-condensing |
| Dimensions | 430mm(W) × 320mm(H) × 98mm(D) |
| Weight | 4.2kg |
Certificates & Compliance
- Standards: EN 54-2 1997 + A1: 2006; EN 54-4 1997+A1: 2002+A2:2006
- Certifications: LPCB
Compatible Devices
- GST-RP16 Repeater Panel
- DC-910xE Series Conventional Detectors
- C-910x Series Conventional Detectors
- DC-9204E Conventional Manual Call Point
- C-940x Series Conventional Sounders and Strobes
Accessories & Tools
- RB116A — Relay Board (Product No. 20101736)
- P-9907 — Active End of Line (Product No. 10102406)
- DP-9907 — Active End of Line (Product No. 10103044)
Part No.: GST116A · Product No.: 10105779
